Thermal 3D mapping by photogrammetry

Thermal mapping of a building front Thermal orthophoto (5cm GSD) made on a building of 130m long and 20m high. Results obtained from 334 thermal infrared images. Source : Drones Imaging company. Area : 2600m². Camera : FLIR Orthophoto : GSD 5cm.   3D viewing

Share Button
Continue Reading

Building Information Model by photogrammetry: Chaumont viaduct

Post Image

BIM (Building Information Model) viaduct located at kilometer point (KP) 260.757 of the Paris-East line to Mulhouse City. Results obtained from 5900 aerial images. Type: masonry vaults. Length: 654m Height: 52m Aerial photographic coverage: 5900 images. Source: Data acquisition & post processing by Drones Imaging. Camera: Sony RX100 III. Orthophoto: GSD 5mm.

Share Button
Continue Reading

Building Information Model (BIM) – Le Pecq viaduct

Post Image

Post processing and images taken by Drones Imaging. Le Pecq, region of Paris: The first step of 3D modeling of the viaduct (by photogrammetry) was sufficiently precise to realize a BIM (Building Information Model). Displayed in software using the 3 dimensions, this model allows to increase productivity in the design and installation of adjacent superstructures such as […]

Share Button
Continue Reading
